Automatic Cement Concrete Block Brick Making Machine Brick Forming Machine

Concrete Block Making Machines for Concrete Brick Production Specifications

Technical Parameter(Block Making Machine)	Detailed Data
Machine Model	QT12-15, QT10-15, QT8-15 QT6-15block making machine
Overall Dimension	8200×2600×3020(mm)
Rated Pressure	21MPa
Main Vibration Form	Platform Vibration
Acceleration of vibration	15-20g
Cycle Time	15-20 seconds
Vibration	100KN
Vibrating Frequency	2800-4500 rolls/minute
Motors Power	66KW
Pallet Size	1420*900(mm)
Weight	14.5T
Raw Materials	Crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, expanded perlite, and other industrial wastes
Applied Products	Concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc.

The Finished Cement Block Products Specifications

Automatic Concrete Cement Brick Block Making Machine Brick Forming Machine

Block Type	Size (mm)	Molding Cycle	Pcs/Mold	Pcs/Hour
Hollow Block	400200200	15-20s	12	2160-2880
Solid Brick	24011553	15-17s	65	5400-7200
Paving Brick	22011050	20-25s	42	6050-7500

What Are the Features of QT10-15, QT12-15 Concrete Block Production Line Machine?

Combining with German Yitong High-tech and Hongfa Technology, this advanced QT12-15, QT12-15 brick concrete making machine is superior to other block production machine in these aspects:

Featuring the best configuration
- Taiwan Calyca Hydraulic
- Imported German Siemens PLC

Passing the strict quality inspection

- CE/SGS/ISO9001:2000

With great performance and power consumption
- Increasing 20% capacity vs others model
- Extremely proving the stability
- Effectively to solve the problems of system halted, holdup, weak pressure, motors burning and consumption in the block machine industry.

Automatic Concrete Cement Brick Block Making Machine Brick Forming Machine

Advantages of Block Making Machine to Produce Concrete Brick

High Density

Designed with particular storage and description material system which insure the feeding accuracy and avoiding the effect of exterior material, this QT10-15, QT12-15 black making machine features high density.

Automatic Concrete Cement Brick Block Making Machine Brick Forming Machine

Flexible Vibration Frequency Adopting frequency conversion motors and synchronization vibration to insure the products making average, and the vibration frequency can be adjusted randomly according to plastic character of various of raw materials.	Achieve Scrutiny, Controlling, and Diagnosis The computer features fault diagnosis system. Warning signal is propitious to eliminate the fault. Combine with long-distance controlling system, it can achieve scrutiny, controlling, as well as diagnosis.
Optimal Material Vibration Low frequency in feeding material and high frequency vibration makes the different materials to have an optimal vibration way. It also helps power saving and improve the efficiency when producing high density, high strenght blocks.	PLC Intelligent Control The control system is equipped with complete logic control, production program, malfunction diagnosis system and remote control function. So it only needs a trained person for operation rather than a professional one.

The Block Making Process with Hongfa Brick Production Machine

Hongfa Block Making Machine Product Lines

What are the Advantages of our Block Making Machine:

One Concrete Forming Machine can make varies types of Hollow blocks,solid bricks,interlock bricks,paver bricks,pavement,kerbstone,ect. Just by chaging the forming molds.

What is the Baking-free or Burned-free brick:

The concrete block and concrete brick made by our block forming machine, no need to bake or burn, the block can cure naturally and gain enough strength for construction purpose. So the cement block or concrete brick are environment friendly products and promoted by many Government around the world.

What are the main Materials to make the hollow block and paving brick:
The main materials can be:crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, expanded perlite, and other industrial wastes.

How big the land area and how many workers required to run the blocks making plant:
Depends on the block making machine capacity, normally 200m2 to 300m2 for installing the block forming machine and block production line, and other land area for finished blocks curing and storage. About 3--5 men for the blocks making line is ok.

How about your concrete block molding machine company/factory?

Hongfa company is direct factory to make the blocks machines in China since the early 1990s, is the largest and most influential manufacturer in concrete block machinery in China mainland, we have exported our machines to more than 76 countries and regions.

We are Direct factory, not midle agent, so the quality and after-sale services is guaranteed.

How about the Guarantee and Installation of the machine?
We provide our clients 3 years guarantee to the main structure of the block making machine, other company is only one year;and we will send engineer to to clients' site to guide the installation of the machines.

How about the  block making machine commissioning of the brick machine and training to workers?
Yes, after finish the installation of the block production line, our engineer will do the testing and commissioning, and make the most suitable ratio of the materials to make the blocks, and train th e
workers how to operate and maintain the machines.

Does your cocnrete block machinery factory has the block machines in stock? if no, how long should wait for the machine shipping?
Yes, the main machines, we always haves diefferent models in stock, but the the mold need to be customized and requires about 2 to 3 weeks to produce the mold accordingly.

Can i visit to your block machinery factory and the cement  blocks making plant?
Yes, welcome to be oue guest in the future, we will be expecting your visit,here you can look around our factory, and also can visit the blocks making plant, we will introduce to you every details and process of how the blocks is made.

How to contact your brick making machine factory?
Our company name: Guangxi Hongfa Heavy Machinery Co.,Ltd
Add: Yilingyan Industry Zone, Nanning City, Guangxi China

With over 20 years' experience in R&D and manufacturing block making machine, fully-automatic brick production line, concrete pipe making machine, concrete mixing plant, as well as light weight EPS wall panel machine, Hongfa Heavy Machinery Co., Ltd. have gained much reputation by its high quality products which meet the ISO9001-2000 standard and with the certificates of CE, SGS, BV etc.

Owning over 67 patents (including invention and practical patents) and gaining "China Well-Known Trademark" honor, Hongfa Machinery is dedicated to providing high quality EPS light wight wall panel making machines to our customers.
