Brief introduction:
The roll forming machines can produce various of steel roof and wall panel, it is a new building materials, the products are widely used as the roof and wall of factory, warehouse, garage, gymnasium, exhibition center, cinema, theatre, etc. It has many advantages, such as easy installation, short building period, beauty, light weight but high strength.




The chart of Process Flow and components
Manual uncoiler- Roll forming machine- Computer control system- Hydraulic control system- Form cutter

Advantages of the roofing sheet roll forming machine
1. High efficiency
2. Lower cost
3. Long life time: 30years
4. Low energy consumption
5. PLC control, Panasonic or Siemens or eura
6. Easy operation
7. Beautiful and best quality

Parameters of the Machine:
1. Suitable material: Color steel plate, Galvanized Board, Aluminum Plate, etc.
2. Suitable thickness: 0.3-0.8mm or other thickness
3. Forming specifications: Depending on specific requirements of customers
4. Forming speed: 15-20m/min
5. Main motor power: 4Kw (depending on specific requirements of users)
6. Cutting mode: Hydraulic cutting
7. Hydraulic station power: 4Kw (depending on specific requirements of users)
8. Control system: PLC systems from Mitsubishi, Schneider and Panasonic products, electrical appliances of famous brands
9. Way of drive: One inch chain
10. Optional accessories: Hydraulic uncoiler.
11. Material of roller: High grade 45# forged steel plated with hard chrome plating

We can also design many kinds of roll forming machines according to your specific profile drawing.
