Automatic Tissue & Spoon & Fork & Knife Packing Machine
$45000.00 /set
Stock: 1000set
Send Inquiry
Seller Support:
Trade Assurance — To protect your orders from payment to delivery
Product Details
Transaction Comments
:
Basic Info
  • Model NO.: PPBZJ-450
  • Packaging Material: Film
  • Driven Type: Mechanical
  • Function: Transport Packaging
  • Application: Drinks, Cosmetics, Skin Care Products, Tea, Vegetable, Fruit, Fish, Meat, Snack
  • Circulation Function: Outer Packing
  • Mode of Operation: Packaging of Export Products
  • Packing Products: Tissue, Pepper Bag, Spoon, Fork, Knife etc
  • Machine Dimension: 8200X1300X1800mm
  • Trademark: POLYPRINT
  • Specification: 450mm
  • HS Code: 8422400000
  • Usage: Packaging of Goods
  • Packaging: Bag
  • Type: Packaging Production Line
  • Packaging Technology: Mildew Proof Packaging
  • Soft and Hardness: Flexible Package
  • Frequency of Use: Several Packaging
  • Packing Material: Film and Paper
  • Speed: 10-100PCS/Min
  • Machine Weight: 1600kgs
  • Transport Package: Wooden Pallet
  • Origin: China
Product Description
Characters
This Automatic Packing Line is all researched and developed by our factory, the controller of the machine is PLC, and the driver is multi-servo. It is integral system of all the electricity. It is our honor because owing three patents. The greatest advantage is this packing line greatly improve the production efficiency and saving labor, and also reduce the second pollution, it is full compliance with health and safety requirements.

Application
This packing line is used for automatic cutting, folding and loading napkin, wet tissue, salt bag, pepper bag etc.  As for customer requirements, this packing line can add straw auto-loading equipment, disposable cutlery auto-packing equipment such as straw, chopsticks, toothpick, napkin, spoon, knife and fork etc.

Napkin Folding Unit
1 Model PPBZJ-450
2 Speed 20-150 bags/min
3 Napkin Dimensions 6 -17 inch
4 Folding Range 6-12 fold
5 Folding width 25-60 mm
6 Max. Napkin Rolls Diameter Φ900
7 Max. Napkin Width 450mm
8 Napkin Embossing Width 330mm
9 Power 3.5kw
10 Packing Line Dimensions 8200x1300x1800mm
11 Weight 1600kg

Horizontal Packing Unit
1 Model PPB-260
2 Max. Film Width 250mm
3 Film Thickness 0.012-0.05mm
4 Packing Speed 20-150 bags/min

5

Finished Packing Size
 		 Length: 100-300mm
Width: 30-80mm
Height ≤35mm
6 Power 3.5kw
7 Packing Line Dimensions 8200x1300x1800mm
8 Weight 1600kg

Auto-loading Unit (Salt Bag, Sugar Bag, Pepper Bag etc)
1 Model PPGZJ-200
2 Max. Loading Speed 150 bags/min
3 Max. Dimension 75mm
4 Control System PLC + Servo Motor
5 Power 3.5kw
6 Packing Line Dimension 8200x1300x1800mm
7 Weight 1600kg

Straw Auto-loading Unit
1 Model PPXG-200
2 Straw Diameter Φ03-Φ06mm
3 Straw Length 100-200mm
4 Loading Speed 20-150 Piece/min
5 Power 3.5kw
6 Packing Line Dimensions 8200x1300x1800mm
7 Weight 1600kg

Automatic Tissue & Spoon & Fork & Knife Packing Machine
