Auto-Positioning System: The all new TUPO 8 E-CONTROL PLUS series is equipped with a state of art, computerized device that can automatically detect the wall plumb, and immediately define the exact adjustments, in order to correct any unevenness.

Other advantages include:In certain circumstances a day can reach 800 square meters, 1000 square meters, 500 square meters for the actual site measurement results / day (10 hours), the one-time plastering width 1000mm, high speed and high precision, more time-saving and convenient.

Description:

1.Remote control

2.30% more bigger mortar tank capacity .

3.Electrically control the flip of plastering trowel,more accurate.

4.render start from ground 28cm.

5.Electric components from international brands Siements,Omron,Japan IDEC,Phoenix.

6.Light weight for the machine,it is easy to move.

7.Easy operation and easy maintenance

Technical parameter

TUPO 8 e-CONTROL PLUS 1000

Other advantages include:
1.New Aluminum Magnesium Alloy main unit and directional poles, supplied by China famous aluminum supplier Feng LV, lighter weight and higher strength.
2.The directional pole can be folded so that it can go through the door and beam of ceiling and around the construction site conveniently,no need to disassemble.
3. Original gear rack driving system enable output of main power more peaceful and stable, 25% faster lifting speed than old generation, improve the plastering efficiency and accuracy.
4. Plaster as much as 2.5m² in about 45 seconds. More efficiently.
5. Auto Positioning System device (APS) which guarantees a perfect and fully automatic alignment, even coating thickness, computerized device that can automatically detect the wall plumb, and immediately define the exact adjustments, in order to correct any unevenness.and make wall more flatness, more precisely.
6. Remote Control available, easily and safely operate the machine from distance if desired.
7. Feed cement mortar by dumper directly, which can save 2/3 of the time, improve the work efficiency.
8. Enlarged mortar tank capacity to 100 liters, and enable to plaster wall surface of 4M without adding mortar anymore.it's more convenient and save labor.
9. Bigger accessible plastering wall surface, decrease the plastering surface to be with rectification by manual labor.
10. Specially designed Plastering Height Control mechanism enables to plaster wall surface under beam, below and above window, corner.








Development of the plastering machine





Our service

I. Normally the service life of our machines can be 3-5 years.

II. We offer 1 year Quality Warranty for our machines.

III. We offer full set of easy-spoiled spare parts and tools for back up.

IV. We can send our engineer abroad to training customers to operate the machine.

V. We resolve any problem together with our customers.



Frequently Asking Questions (FAQ):

I. What is RENDERING MACHINE?

RENDERING MACHINE is also called Automatic Rendering Machine, Automatic Plastering Machine, Wall Rendering Machine, Wall Plastering Machine Etc. It is unique and perhaps one kind of automated rendering machinery ideally suitable for the construction/building industry. It works with conventional cement mortar which brings it to a smooth, flat finish with variable and adjustable thickness to suit each application.

II. What finish can be achieved?

Depending on how fine or course the sand is, our RENDERING MACHINE can produce smooth and flat render finish.

III. How much thickness should be applied?

The same principles apply as the way you render by hand. However, if required, RENDERING MACHINE enables you to achieve from 5 mm up to 30mm render.

IV. What is the render height ?

It can reach up to 5 meters.

V. How is the render quality?

There are two vibrators on the rendering trowel, which gives you a high quality render. RENDERING MACHINE enables you to get finish render as follows:

Vertical : the difference between top and bottom is within 2 mm.

Horizontal: the difference from side to side is within 2 mm.

VI. Does machine need a special mix or compound?

No, the mortar recommended for RENDERING MACHINE is the same mortar that you use when render by hand. It can work with the traditional cement mortar, however lime or gypsum or other additives can be added into the mixture if needed.

VII. How is RENDERING MACHINE used?

Operating our RENDERING MACHINE is as easy as 1, 2, 3.

1. Secure machine

2. Load mortar

3. Press start button

VIII. Is it difficult to operate RENDERING MACHINE?

No. It's very easy to operate RENDERING MACHINE and it doesn't require special or advanced technical training. Half a day's training is enough for a person to operate machine themselves.
