High Precision 30mm Carbon Steel Balls for Pen Sex Toy
$0.01 /piece
Stock: 1000piece
Send Inquiry
Seller Support:
Trade Assurance — To protect your orders from payment to delivery
Product Details
Transaction Comments
:
Basic Info
  • Model NO.: Carbon Steel Ball
  • Certification: ISO, BV, SGS, Ts 16949
  • Universal: Yes
  • Material: Carbon Steel Ball
  • Grade: G40-1000 Bicycle Steel Ball
  • Material Mark: AISI1010/ AISI1015/ C15/ 1.0413/ JIS Swrm 12/ En32
  • Shape: Solid Round Bearing Steel Ball
  • Model No.: AISI1010 Low Carbon Steel Ball
  • Magnetic: Yes
  • Transport Package: Box, Plastic Bag, Carton, Pallet
  • Origin: Jiangsu, Changzhou
  • Customized: Customized
  • Standard Parts: Yes
  • Type: Ball
  • Size Range: 1mm-180mm Bicycle Steel Ball
  • Hardness: 60 Min. HRC (Surface-Hardend)
  • International Equivalent: 1010, S10c, DC01, 1.0330, C10c, 1.0214
  • Certifications: BV; ISO; ASTM
  • Application: Low Quality Bearing, Oiler, Roller, Sliding
  • Trademark: SUHUA
  • Specification: 5mm carbon steel ball
  • HS Code: 8482910000
Product Description
   High Precision 30mm Carbon Steel Balls for Pen Sex Toy
Featrue:
1. Casehardened surface balls and low hardness core.
2. Good characteristics of superficial hardness, low resistance to corrosive attack, magnetic.
3. Used in cycle industry, and yet remain substantially cheaper than balls manufactured
from high carbon chrome alloy steel.

Specification:
Low carbon steel ball
1. Material AISI1010/ AISI1015/ C15/ 1.0413/ JIS SWRM 12/ EN32 ASTM A/29
2. Size Range 1mm-180mm
3. Grade G40-1000
4. Hardness 60 min. HRC (Surface-hardend)
5. Characteristic (a)Casehardened surface balls and low hardness core
(b)superficial hardness
(c)Low resistance to corrosive attack
6. Magnetic Yes
7. Application Low quality bearing, oiler, roller, sliding block
8. Chemical composition
  C% Si%  Mn% Cr%  Ni% Mo% P% S%  Al% Cu%
min. 0.12 --- 0.30 --- --- --- ---- --- --- ---
max. 0.17 0.30 0.60 0.20 0.25 0.05 0.035 0.035 0.01 0.3
9.Packing Standard: 10kg or 20kg per carton,
1 ton per pallet or as customer required
10.Conditioning  dry or oiled
11.Delivery time Stock within a short time or 35 days.
CHANGZHOU HUARI STEEL BALL CO., LTD.

Application:
High Precision 30mm Carbon Steel Balls for Pen Sex Toy

Production process:
Manufacture process of steel balls
Step 1 Heading Balls blanks are cold headed from rolls of wire.
Step 2 Flashing Rolling balls between two hard alloy plates to removes the slight band
and small protrusions.
Step 3 Heat treat Heating balls to a high temperature in furnace and quenching balls in a liquid bath.
Step 4 Rough grind Rolling balls between the face of a fixed iron plate and a very hard fire-grit grinding wheel. Then rolled the hardened ground balls between two cast iron plates.
Step 5 Cleaning The final production operation cleans the finished balls and adds a shiny luster.
Step 6 Final
          Inspection		 Balls are gauged, visually inspected and subjected to other quality tests to insure
every customer's specifications are achieved.
Step 7 Packaging The balls are packaged in accordance with customer specifications for shipping.


High Precision 30mm Carbon Steel Balls for Pen Sex Toy

Packaging:
Type 1: Plastic bag + box + carton + wooden pallet
Type 2: Plastic bag + carton + wooden pallet
Type 3: Our package: export cartons, steel drums, wooden pallets

High Precision 30mm Carbon Steel Balls for Pen Sex Toy

About us:
1. Established since year 1986, more than 27 years experience and specialized in steel balls manufacturer and ball related products.
2. High precision instruments and technical staffs.
3. Offer the good quality service and product with short delivery times.
3.175mm Stainless Steel Ball AISI 420c G100

Mian products:
High Precision 30mm Carbon Steel Balls for Pen Sex Toy


Services:
1. All the inquiries will be reply within 24 hours
2. For the steel ball, please kindly let us know the size, material, grade and quantity.
3. For the bearing, please kindly let us know bearing type, material, Accuracy Grade/Class, and quantity.

Certification:
High Precision 30mm Carbon Steel Balls for Pen Sex Toy

FAQ:

Q1: What kind of ball can supplied by Huari?

A: Stainless steel ball, Chrome steel ball, Carbon steel ball, Brass ball, Aluminum ball, Copper ball, coated ball.


Q2. What is your terms of payment?

A: T/T 30% as deposit, and 70% before delivery.


Q3. What is your terms of delivery?

A: EXW, FOB, CFR, CIF.


Q4: How many days for delivery?

A: Inventory with 1-3 days or 25-30 days. The specific delivery time depends on your quantity.

Contact us:
Tel: +86-519-81181030*609
Phone No: +86-18306129019  Lucy


Any futher query, please do contact us anytime.
