NEW 250CC chopperI motorcycle/cruiser motorcycle/wheel motorcycle(MC-684)

Engine
Type: ZonGSHEN 249.4cc, single-cylinder, 4-valve, 4-stroke, water-cooled
Bore x Stroke: 70mm x 64.8mm
Max Power Out: 16/8500 kw/(r/min)
Starting System: Electric start & kick start
Max speed: 135km/h
Clutch Type: Heavy Duty Wet Multiplate
Transmission: 5 SPEED Manual - 1N2345 (1 Down, 4 Up)
Carburetor: 30mm Carburetor
Ignition: CDI
Fuel Type: High Octane Unleaded Fuel (92 or higher)
Engine Oil Grade: Non Synthetic 10W/40SF 4 Stroke Engine Oil
Magneto Type: Electronic Ignition System
Final Drive: Gold KMC #520 Chain
Spark Plug: Genuine NGK Spark Plug

Material
Twin Spar Steel frame
Steel Swingarm
Alloy Triple Clamps
Alloy Handlebar
Alloy Wheels
Alloy Hubs
Alloy Gearshift
Alloy Clutch and Brake Lever
Alloy Fuel Cap
Alloy AB Lever
Alloy hollow axle
Alloy Rear Sprocket
Alloy Exhuast Pipe
Handlebar Grip Soft High Grip Rubber
New design 2011 CRF250 Plastic Body
New and high quality design seat
New and high quality disk brakes
Twin Liquid Radiator with fan
New and high quality design big bore exhaust pipe
New and high quality design chain guard
New and high quality Lock Switch

Suspension/Brake/wheels
Front Suspension: Oil damper & air-cell adjustable, 920mm length, 58mm dia, 200mm travel
Rear Suspension: Air-cell adjustable, 480mm length, 86mm dia, 110mm travel
Front Brake: Hydraulic single disc with twin-piston calliper/270mm dia disc
Rear Brake: Hydraulic single disc with twin-piston calliper/240mm dia disc
Front Wheel: Alloy Wheels 80/100-21" with high quality off road tyre
Rear Wheel: Alloy Wheels 110/90-18" with high quality off road tyre

Dimensions/packing
L x W x H: 2100 x 810 x 1260mm
Seat Heigth: 935mm
Wheelbase: 1425mm
Ground Clearance: 360mm
Tank capability: 9L
Carton size L/W/H: 1835 x 490mm x 1065mm
1 x 20'FT Container: 30pcs
1 x 40'HQ Container: 62pcs

frame colour: Black or Silver
Cover colour: Black, Red and White








about FAQ

1. Q: What is UTV?

A: UTV is the abrreviation of Utility Vehicle, namely a vehicle, which
Can be used as a tranportation tool in forest, hilly area, farm, and mine field, it can be also used in sports and relex, fire contro, patrol and security system.



2. Q: What can TNS UTV do for you?

A: Our UTV owns the whole characters which the the other UTV has. Its functions are as follows:

1) cargo loading in forest, hilly and farm area, such as log, rick and some animal.

2) Transportation tools

3) Guarding system



3. Q: How about the after sale system of your products?

A: Generally, we promise one year's free maintanance for the main parts
Such as engine, and six months for the easily broken parts. And we also provide suitable instruction to send our engineer to your country to help solve the problem if needed.



4. Q: Can we use our own logo and design?

A: Of course you can. But usually you provide the logo design and
We do the stickers for you, if just for samples, we will add some extral fee for it consindering the whole cost.



5. Q: If we want to visit your factory, which is the nearest international and domestic airport?

A: Our factory is located in Yongkang city, zhejiang province, here are three airports you can chose:
Yiwu, hangzhou and shanghai. And you can also take fast train to JInhua west station, and we can pick up you
Fron there. Both yongkang west and east station is available.

Warranty time
We supply you 6 month for warranty time, during the warranty time, we supply you free parts! !
