Pwht Flexible Ceramic Pad Heater Clawer Type Ceramic Heater
-
10-99 piece
US $ 49
-
100-499 piece
US $ 48
-
>=500 piece
US $ 45
Hits
45
Total Stock
1000 piece
feedback()
VIEW ALL
Item Details
Basic Info
- Model NO.: pad heater
- Type: Ceramic Pad Heater
- Form: Heating Wire
- Voltage: 60V,80V
- Size: Customised
- Transport Package: Carton Box
- Origin: China
- Certification: RoHS, UL, ISO9001, CE
- Material: High Alumina Ceramic
- Shape: Plate
- Power: 1.35kw,2.7kw,etc.
- Trademark: HEATFOUNDER
- Specification: Clawer Type Ceramic Heater
- HS Code: 8615800000
Product Description
PWHT Flexible Ceramic Pad Heater Clawer Type Ceramic Heater
Description:
Flexible ceramic pad heater fast heat raising, high hot utilization, significant energy-saving, low labor intensity, safe and reliable to use, , easy to operate performance, production is not limited by the models and specifications. Its one of the most from the size of the welding industry is currently one of the most ideal innovative and practical Heat Treatment heater. Maximum working temperature of 1050 degrees. Ceramic pad heater can be adapted, especially in chemical fiber, plastics, plastic machinery, electronics, medicine, food and a variety of heating pipeline voltage from 36V, 110V, 180V, 220V, 380V, maximum power load 6.5W/m2, compared with the traditional electric heater energy consumption can be reduced by 30%
Standard types:
What can we do for you?
1. Sample is available.
2. Independent R&D, ISO manufacture, precise quality standards, modern logistics management, and sound marketing strategy.
3. Inquiry replied within 24 hours.
4. Patented products.
5. OEM or ODM is available.
6. Some extra accessories can be supplied.
7.The larger quantity you order,the more competitive prices you'll get.
8. Neccessary Certificates can be supplied.
Description:
Flexible ceramic pad heater fast heat raising, high hot utilization, significant energy-saving, low labor intensity, safe and reliable to use, , easy to operate performance, production is not limited by the models and specifications. Its one of the most from the size of the welding industry is currently one of the most ideal innovative and practical Heat Treatment heater. Maximum working temperature of 1050 degrees. Ceramic pad heater can be adapted, especially in chemical fiber, plastics, plastic machinery, electronics, medicine, food and a variety of heating pipeline voltage from 36V, 110V, 180V, 220V, 380V, maximum power load 6.5W/m2, compared with the traditional electric heater energy consumption can be reduced by 30%
Standard types:
| 60V Heaters | |||||
| Type | Width(mm) | Length(mm) | Rating(kW) | Current(amp) | Voltage (V) |
| CP3-60V | 75 | 724 | 2.7kW | 45amp | 60V |
| CP4-60V | 102 | 533 | 2.7kW | 45amp | 60V |
| CP6-60V | 152 | 368 | 2.7kW | 45amp | 60V |
| CP8-60V | 203 | 267 | 2.7kW | 45amp | 60V |
| CP10-60V | 254 | 229 | 2.7kW | 45amp | 60V |
| CP12-60V | 305 | 184 | 2.7kW | 45amp | 60V |
| CP15-60V | 380 | 146 | 2.7kW | 45amp | 60V |
| CP18-60V | 457 | 127 | 2.7kW | 45amp | 60V |
| CP21-60V | 535 | 102 | 2.7kW | 45amp | 60V |
| CP24-60V | 610 | 83 | 2.7kW | 45amp | 60V |
| CP26-60V | 740 | 83 | 2.7kW | 45amp | 60V |
| 80V Heaters | |||||
| Type | Width (mm) | Length(mm) | Rating (kW) | Current (amp) | Voltage (V) |
| CP3-80V | 75 | 991 | 3.6 kW | 45amp | 80V |
| CP4-80V | 102 | 737 | 3.6 kW | 45amp | 80V |
| CP6-80V | 152 | 501 | 3.6 kW | 45amp | 80V |
| CP8-80V | 203 | 368 | 3.6 kW | 45amp | 80V |
| CP10-80V | 254 | 368 | 3.6 kW | 45amp | 80V |
| CP12-80V | 305 | 248 | 3.6 kW | 45amp | 80V |
| CP15-80V | 380 | 203 | 3.6 kW | 45amp | 80V |
| CP18-80V | 457 | 165 | 3.6 kW | 45amp | 80V |
| CP21-80V | 535 | 145 | 3.6 kW | 45amp | 80V |
| CP24-80V | 610 | 125 | 3.6 kW | 45amp | 80V |
| CP29-80V | 740 | 100 | 3.6 kW | 45amp | 80V |
| CP33-80V | 840 | 85 | 3.6 kW | 45amp | 80V |
| CP36-80V | 915 | 80 | 3.6 kW | 45amp | 80V |
Detailed pictures:
What can we do for you?
1. Sample is available.
2. Independent R&D, ISO manufacture, precise quality standards, modern logistics management, and sound marketing strategy.
3. Inquiry replied within 24 hours.
4. Patented products.
5. OEM or ODM is available.
6. Some extra accessories can be supplied.
7.The larger quantity you order,the more competitive prices you'll get.
8. Neccessary Certificates can be supplied.
