1.2mm/1.5mm/2.0mm Reinforced Tpo Waterproof Membrane
US $ 4.00
Hits
193
Total Stock
1000 square meter
feedback()
VIEW ALL
Item Details
Basic Info
- Model NO.: GFM-T
- Ceiling Tile Shape: Roll
- Thickness: 1.5mm
- Surface Treatment: Smooth or Fabric Coated
- Certification: ISO, MSDS, CE
- Usage: Roof, Underground Construction, Tunnel
- Elongation at Break: 500%
- Resistance to Impact: 0.5kg*M, No Leakage
- Trademark: Kintop
- Specification: Length 20m or customized
- HS Code: 3919109900
- Type: Waterproof Roll Material
- Material: Tpo
- Ceiling Tile Type: Tpo
- Function: Fireproof, Waterproof
- Color: White, Grey, Green, Blue, Red Can Be Provied
- Tension Strength: 12MPa
- Cold Flexibility: -40 Degree Centigrade, No Cracks
- Features: Long Service Life, Anti-Aging
- Transport Package: Roll
- Origin: Shandong, China
Product Description
1.2mm/1.5mm/2.0mm Reinforced TPO waterproof membrane
1.Features:TPO waterproof membrane
1)Weather resistance and durability.
2)Excellent weld ability.
3)No any crisp agents to prevent materials brittleness.
4)Intermediate resistance suitable for mechanically fastening roofing system.
5)Excellent the same high and low temperature resistance as rubber materials which
can keep flexible at -50ºC and keep mechanical strength in high temperature.
6)Excellent chemical resistance to acids,bases,and restaurant exhaust emissions.
7)Dimension atablility.
8)White-based light color and smooth surface with high reflection,engery saving and anti-dust
functions.
9)Use heat welding for the seam areas to form a reliable seamless waterproof layer.
2.Specification:TPO waterproof membrane
3.Technical date:GB27789-2011
4.Use scope:TPO waterproof membrane
1) It's widely used for industrial and civil construction.
2) Underground engineering,such as dam,subway,tunnel,bridge,etc.
5.Construction:TPO waterproof membrane
According to the characteristics of different projects,general use mechanical fastening,cold
applied,etc.Involved tools are hot air gun,hot air welding machine.
6.About us
Shandong Jinding(Kintop) waterproof technology co., ltd. is located in waterproof building materials Town - Shouguang City, TaiTou town industrial park,China. Founded in 1998, is a manufacturer of waterproof materials,PVC waterproof membrane with well-equipped testing facilities and strong technical force.We have more than 20 years experiences in waterproofing,professional and technical person,complete testing equipment,stable and reliable product quality.
Our main products are : polyvinyl chloride (PVC) waterproof membrane,TPO/EPDM waterproof membrane,self-adhesive bitumen waterproof membrane/flash bond tape, geomembrane, etc. We mainly export to Southeast Asia,Western Europe,America,etc.
With a wide range,good quality,reasonable prices and stylish designs,our products are extensively used in waterproofing and other industries.
We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success !
1.Features:TPO waterproof membrane
1)Weather resistance and durability.
2)Excellent weld ability.
3)No any crisp agents to prevent materials brittleness.
4)Intermediate resistance suitable for mechanically fastening roofing system.
5)Excellent the same high and low temperature resistance as rubber materials which
can keep flexible at -50ºC and keep mechanical strength in high temperature.
6)Excellent chemical resistance to acids,bases,and restaurant exhaust emissions.
7)Dimension atablility.
8)White-based light color and smooth surface with high reflection,engery saving and anti-dust
functions.
9)Use heat welding for the seam areas to form a reliable seamless waterproof layer.
2.Specification:TPO waterproof membrane
| Product name | TPO waterproof membrane |
| Brand | Kintop |
| Thickness | 1.0mm,1.2mm,1.5mm,2.0mm |
| Width | 1.0m,1.5m,2.0m |
| Length | 20m |
| Type | H type,L type,P type |
| Remark | Specification can be customized. |
3.Technical date:GB27789-2011
| NO. | ITEM | INDEX | |||
| H | L | P | |||
| 1 | The resin thickness of middle fabric/mm ≥ | - | - | 0.4 | |
| 2 | Tensile strength |
Maximem tension/N/cm ≥ | - | 200 | 250 |
| Tension strength/Mpa ≥ | 12 | - | - | ||
| Maximum tension elongation/≥ | - | - | 15 | ||
| Fracture elongation%/ ≥ | 500 | 250 | - | ||
| 3 | Heat treatment size change rate/% ≤ | 2 | 1 | 0.5 | |
| 4 | Low temperature bend | -40ºC No crack | |||
| 5 | Water tightness | 0.3Mpa,2h,no seepage | |||
| 6 | Attack resistence | 0.5kg*m,no seepage | |||
| 7 | Static charge resistence | - | - | 20kg,no seepage | |
| 8 | Seam strip strength/(N/mm)≥ | 4.0 or membranes break | 3 | ||
| 9 | Right-angle tear strength/(N/mm)≥ | 60 | - | - | |
| 10 | Trapezoid tear strength/(N/mm)≥ | - | 250 | 450 | |
| 11 | Bibulous rate(70ºC,168h)/%≤ | 4 | |||
4.Use scope:TPO waterproof membrane
1) It's widely used for industrial and civil construction.
2) Underground engineering,such as dam,subway,tunnel,bridge,etc.
5.Construction:TPO waterproof membrane
According to the characteristics of different projects,general use mechanical fastening,cold
applied,etc.Involved tools are hot air gun,hot air welding machine.
6.About us
Shandong Jinding(Kintop) waterproof technology co., ltd. is located in waterproof building materials Town - Shouguang City, TaiTou town industrial park,China. Founded in 1998, is a manufacturer of waterproof materials,PVC waterproof membrane with well-equipped testing facilities and strong technical force.We have more than 20 years experiences in waterproofing,professional and technical person,complete testing equipment,stable and reliable product quality.
Our main products are : polyvinyl chloride (PVC) waterproof membrane,TPO/EPDM waterproof membrane,self-adhesive bitumen waterproof membrane/flash bond tape, geomembrane, etc. We mainly export to Southeast Asia,Western Europe,America,etc.
With a wide range,good quality,reasonable prices and stylish designs,our products are extensively used in waterproofing and other industries.
We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success !
