IP54 24G Microwave Motion Sensor for Automatic Sliding Door System
$14.00 /piece
Product Details
Transaction Comments
Basic Info
- Model NO.: GV-606
- Usage: Motion Detect to Open Door
- Certification: CE
- Technology: Microwave&Microwave Disposer
- Transmitting Power: 20dBm Eirp
- Installation Height: 4m
- Detection Speed: 5cm/S
- Protection Class: IP54
- Trademark: GARVIEW
- Specification: 120mm(W)*80mm(H)*50mm(D)
- Type: Sensor
- Installation Mode: Wall Mounted
- Application: Home, Industry, Commercial Places
- Frequency: 24.125GHz
- Launch Frequency Density: 5MW/Cm2
- Detection Mode: Motion Type
- Detection Range: Detection Range:4m*4m(Installation Height 2.2m)
- Dimension: 120mm(W)*80mm*50mm(D)
- Transport Package: Durable Carton Package
- Origin: China
Product Description
IP54 24G Microwave Motion Sensor for automatic sliding door system
Product Parameters
Product Parameters
| Technology | Microwaveµwave disposer |
| Frequency | 24.125GHz |
| Transmitting power | 20dBm EIRP |
| Launch frequency density | 5mW/cm2 |
| Installation Height | 4M(MAX) |
| Installation Angle | 0-90 degree |
| Detection Mode | Motion Movement |
| Min detection speed | 5cm/s |
| Power | 2W(VA) |
| Detection range | 4m*4m(Installation Height 2.2M) |
| Maximum voltage | 42AC-60V DC |
| Maximum Current | 1A |
| Maximum switching power | 30W(DC)/60VA(AC) |
| Retention time | 0.5S |
