Auto Loading Circular Saw Cutting Machine for Rectangular Pipe
$8000.00 /set
Product Details
Transaction Comments
Basic Info
- Model NO.: YS-350CNC-L
- Layout: Vertical
- Automatic Grade: Automatic, Manual, Semi-Automatic
- Cutting Mode: Saw Cutting
- Blade Used: 250/275/315/350
- Transport Package: Standard Export Package
- Origin: China
- Customized: Customized
- Cutting Material: Copper, Carbon Steel, Iron, Aluminum, Metal Alloy, Stainless Steel
- Power Source: Electric
- Color: Blue(Customized)
- Trademark: YOUSHENG
- Specification: 700kg
- HS Code: 8462399000
Product Description
Autoloading tube cutting machine/Square tube auto load cutting machine
YS-350
YS:Metal Circle Sawing Machine
350: The suitable saw blade can be installated ¢350
Features
Auto loading
1. Servo feeing, high precision.
2. Equiped with tailing parts, save the material, no waste.
3. Easy Operation and Maintenance.
4. Process steps showed in Chinese and English on the screen.
5. Easy operator Interface and easy data input.
6. Automatic feeding,length-fixing,automatic clamping abd automatic cutting.
7. Vertical cut and champer cut change freely.
8. Automatic foot switch,pressing and sawing.
9. Automatic water cooling system makes the cutting surface smooth and of little flash and strain, also makes the saw blade long-time use
.
Manufacture:
YS-350
YS:Metal Circle Sawing Machine
350: The suitable saw blade can be installated ¢350
Features
Auto loading
1. Servo feeing, high precision.
2. Equiped with tailing parts, save the material, no waste.
3. Easy Operation and Maintenance.
4. Process steps showed in Chinese and English on the screen.
5. Easy operator Interface and easy data input.
6. Automatic feeding,length-fixing,automatic clamping abd automatic cutting.
7. Vertical cut and champer cut change freely.
8. Automatic foot switch,pressing and sawing.
9. Automatic water cooling system makes the cutting surface smooth and of little flash and strain, also makes the saw blade long-time use
.
| Model | YS-315FA | YS-350FA |
| Round | ¢80mm | ¢100mm |
| Square | 60×60mm | 100×100mm |
| Rectangle | 60×80mm | 100×120mm |
| Round bar | 38mm | 45mm |
| Square bar | 38mm | 45mm |
| Main motor | 4kw | 4kw |
| Spindle speed | 120/60RPM | 80/40RPM |
| Suitable blade | ¢250-¢275mm | ¢250-¢350mm |
| cooling system | Automatic cold cycle series | |
| Size | 2600*800*1900mm | 2900*900*2000mm |
| Weight | 750kg | 850kg |
Manufacture:
