- Model NO.: CFY01/CFY01A
- Loading Weight: Tanker Trailer Part
- Tent Type: Simple
- Tire Number: Tanker Trailer Part
- Condition: New
- Working Temperature: -40---+60
- Trademark: JIALONG
- Origin: Wenzhou, Zhengjiang, P. R. C
- Certification: SGS, CE
- ABS: Tanker Trailer Part
- Axle Number: Tanker Trailer Part
- Color: Yellow
- Working Voltage: 12VDC
- Working Current Flow: <5mA
- Specification: API, CE, SGS, PEI, ISO
Specifications
2.Working temperature:-40 -- +60
3.Anti-explosion class:Exia 2 BT4
4.Working current flow:< 5mA
1. Feature & Benefit
The Optic Sensor is installed in the Fuel Tanker Truck when doing the bottom loading work, it will detect the inside situation of the tanker, with the platform of the filling system to ensure the safety of the bottom loading to avoid the leakage.
CFY01 Optic Sensor, CFY02 Optic Socket, CFY03 Ground Blot, the three parts make the CFY Optic Sensor Kit has passed the National Supervision and Inspection Center's test according to the following standard: GB3836.1-2000
Explosive gas atmospheres for Electrical Equipment,part 1 :General requirements
GB3836.4-2000
Explosive gas atmospheres for Electrical Equipment,part 4 : Intrinsically safe"I"
Product explosion-proof sign :ExiaIIBT4
explosion-proof qualified number :GYB091446X
2. Installment Drawing
